| Certification: | ISO, CE |
|---|---|
| Condition: | New |
| Rated Load: | 1-3t |
| Transmission: | Hydraulic |
| Load and Unload Mode: | Front Discharge |
| Walking Mode: | Wheeled |
Specification:
| Engine model | Yunnei brand,Diesel engine |
| In-line,water cooling,4-stroke,Four cylinder | |
| Rate power:76KW | |
| Rated speed:2400rpm | |
| Option:Yuchai engine(85KW), Cummins engine(74.5KW) | |
| Transmission | Hydraulic torque converter transmission; Shaft wheel brake |
| Bucket size | 1.3m3 |
| Bucket width | 2200mm |
| Bucket type | Bucket with teeth |
| Rated loading capacity | 2500kg(Including attachments) |
| Kerb weight | 6900kg |
| Dimension | 6800x2200x2900mm |
| Max lifting height | 5700mm |
| Pin axles height | 5200mm |
| Operation system | Steering system,hydraulic steering |
| Driving mode | Hydraulic system,4WD |
| Quick change system | KAT / Volvo /SM |
| Control system | Hydraulic lever control |
| Brake system | Brake system of safety auxiliary air disc brake; Hand brake |
| Tires | 16/70-20,Width:380mm,Diameter:1075mm |
| wheelbase | 2550mm |
| Wheel track | 1700mm |
| System pressure | 20Mpa |
| Pressure output | 96L/min |
Our service
| Pre-Sales Service: | After Sales Service: |
| * Inquiry and consulting support. * Oversea sample testing support. * Visiting our Factory. * Transporting from factory to door | * Training how to instal the machine, * Training how to use the machine. * Engineers available to service machinery overseas. * Warranty and whole workling life service |
