Product Description
The mixer truck is composed of automobile chassis, mixing drum, transmission system, water supply device, full power power power take-off device, front and rear bracket of mixing drum, reducer, hydraulic transmission system, feeding and discharging system, control mechanism, etc.
Appearance:
The tank material of the mixing tank is alloy steel manganese steel, which has higher strength.
The mixing blade is double helix logarithmic thickened blade, which is more wear-resistant.The inner blade is made of fine grain alloy steel with unique Angle design, more uniform stirring and lower discharge residual rate.Thickening high - quality wear - resistant alloy steel head, more stable and compact.
Specification
Adopting the engine and gearbox independently developed by China National Heavy Duty Truck Group, it saves fuel and worry, and after-sales service is more convenient. The high-end atmosphere of the cab is upscale.
Drive form: | 6X4 |
Body size: | 9.9×2.5×3.99m |
Front suspension/rear suspension: | 1.5/3.025 meters |
Wheelbase: | 4025+1350mm |
Rated load: | 11.8 tons |
Vehicle weight: | 13.07 tons |
Maximum speed: | 85km/h |
Front track/rear track: | Front track: 2022, rear track: 1830/1830mm |
engine model: | Sinotruk WD615.95E |
Number of cylinders: | 6 |
Maximum output power: | 247kW |
Maximum horsepower: | 336 horsepower |
Displacement: | 9.726L |
Emission Standards: | National Three |
Engine form: | Inline |
Vehicle announcement: | CSC5257GJBZ12 |
Vehicle type: | Concrete mixer truck |
Slump: | 40.23mm |
Speed of mixing drum: | 6-12r/min |
Feeding speed: | 3m³/min |
Discharge speed: | 2m³/min |
Residual rate of discharge: | <0.7% |
Fill rate: | 58.7% |
Water supply method: | Air pressure water supply |
Hydraulic system: | Closed hydraulic circuit |
Water tank volume: | 500m³ |
other: | Can be used as 10/12 cubic mixing drum |
Gearbox model: | Sinotruk HW15710 |
Number of gears: | 10 gears |
Chassis brand: | Sinotruk Howo (HOWO) |
Chassis model: | ZZ1257N4048W |
Front axle description: | HF9T |
Rear axle description: | HC16T |
Number of springs: | 9/12 |
Number of tires: | 10 |
Tire specifications: | 12.00-20 |
