Brand New SINOTRUK HOWO NX Concrete Mixer Truck Factory Price
Tel/WeChat: +86 13573810060
WhatsApp: +86 13573810060
Email:qdsatatruck@sinosata.com
| Vehicle Specification | Description |
| Type of Vehicle | 8/9/10/12m3 Concrete Mixer Truck |
| Truck Brand | SINOTRUK—HOWO |
| Driving Position | Left hand Driving |
| The Total Mass | 31,000kg |
| Oil Tank Volume | 400L |
| Manufacture | China |
| Chassis & Add Components | |
| Frame Details | parallel ladder with U-profiles and riveted cross members |
| Dimension(LxWxH) | 10150x2496x3990 |
| Wheel base (mm) | 1800+3050+1350 |
| Engine | |
| Model | WP10.380/WP12.400/WP12.430 |
| Power | 380HP/400HP/430HP |
| Type | water-cooled，four strokes，6 cylinders in line，turbocharged, directly injection |
| Clutch & Gear Box System | |
| Clutch | SINOTRUKΦ430mm diaphragm spring clutch |
| Gear Box | HW19710 10 forwards and 2 reverse. |
| Axles | |
| Front Axle Model | VGD95 axle. Capacity: 2*9500kg |
| Rear Axle | HC16/MCX16ZG axle. Capacity:2X 16000kg |
| Brake System | |
| Service brake | Dual circuit compressed air brake |
| Parking brake | spring energy, compressed air operating on rear wheels |
| Auxiliary brake | Engine exhaust brake |
| Steering system | |
| Model | Standard |
| Wheels & Tyres | |
| Type | 12.00R24 |
| Cabin | |
| Type | HW76 standard cabin |
| Mixer Body | |
| Agitating Capacity | 12m3 |
| Water supply | Pressing type |
1. RORO:Fast,Safe and Protect the truck
2. Bulk Cargo Vessel:Lower cost
3. Flat Rack container:every week shipment, competitive shipping cost, but high port charge.
